Features This turmeric powder packing machine is equipped with dual CPU microcomputer control system, liquid crystal Chinese/English display, user-friendly interface, automatic cursor detection and tracking, the operation is more simple. Equipped with high-precision stepper motor to ensure the accuracy of the sealing position of each package.

Performance Of Turmeric Powder Packing Machine :
Adopting the screw to push the feeding method, the packaging weight can be adjusted directly in the packaging process, the adjustment process does not need to stop, effectively improving the working efficiency.

Use:
Suitable for milk powder, soy milk powder, lotus root starch, dyed powder, seasoning powder, medicine powder and other powder automatic measurement packaging.

Features Of Pouch Packing Machine:
1. Control system using PLC program control, touch-type Chinese / English HMI, two servo drive system, bag length, packaging speed, counting, machine fault can be displayed on the touch screen.
2. Horizontal sealing system up and down reciprocating servo motor to provide power to complete the traction of the packaging film, the traction process of packaging materials will not be deformed, reliable photoelectric tracking, bag length is accurate, the bag sealing formation, beautiful.
3. Motion trajectory controlled by the program During high-speed movement, no noise, high sealing strength.
4. Translational adjustable volume measuring bucket, easy adjustment, reducing the material damage and waste.
5. The overall framework of the machine made of stainless steel, smooth, easy to clean.
6. According to the measurement and the requirement of the package, it can realize single package, joint and other forms of packaging.
7. The parts in contact with the material are made of high-quality stainless steel and comply with GMP requirements. Easy to disassemble, assembly, versatility.

If you need fill the turmeric powder into bottle,please visit Powder Filling Machine.

Technical Data

Model	LG-350	LG-500
Bag Size Racking	L: 50-320mm    W: 30-150mm	L: 40-320mm   W: 40-220mm
Packing Speed	20-60Bags/min	30-60Bags/min
Measure Range	10-200g	200-1000g
Thickness Of The Packing Film	0.04-0.08mm	0.03-0.07mm
Total Power	1.8KW/220V	1.8KW/220V
Diameter of the Rolling Paper	=<400	=<400
Machine size	820x900x1980mm	950*1200*1900 (mm)
